HAUPTPARAMETER
| Model | HPPS 2500B | HPPS 1750C | HPPS 2500C | HPPS 3500C |
DC
Parameters | Number of DC Input Channels | 12 | 1 | 1 | 2 |
| Max. DC Current | 209A*12 | 1962A | 2810A | 3934A |
| DC Voltage Operating Range | 1000V~1500V |
|
AC
Parameters | Total Rated Power | 2500kW | 1750kW | 2500kW | 3500kW |
| Max. Output Power | 2750kVA | 1925kVA | 2750kVA | 3850kVA |
| Rated Voltage | 690Vac |
| Isolation Mode | Transformer Isolation |
| Q Range | 0~2625kvar | 0~1837kvar | 0~2625kvar | 0~3675kVar |
| On-Grid Mode | Rated Grid Voltage | 6~35kV (Customizable) |
| Rated Grid Frequency | 50Hz / 60Hz |
| THD | <3% |
| Power Factor | -1~1 |
| Transformer Parameters | Rated Capacity | 2500kVA | 1750kVA | 2500kVA | 3500kVA |
| Transformer Type | Oil-immersed Transformer |
| LV/MV Voltage | 0.69 / (6~35)kV |
System
Parameters | Dimensions (W*H*D) | 6058*2438*2896mm |
| Operation Temperature | -40℃~+60℃ (Derating above 45℃) |
| Operation Humidity | 0~100% |
| Operating Altitude | ≤5000m (No derating within 3000m) |
| IP Rating | IP54 (PCS IP66) |
| BMS Communication | RS485 / CAN |
| EMS Communication | Ethernet Interface |
| Communication Protocol | Modbus RTU / Modbus TCP / IEC104 / IEC61850 |
| Standard Compliance | GB/T 34120, IEC62477, IEC61000, EN50549 |
| Grid Support | CEPRI HLVRT, Frequency adjustment function, Voltage adjustment function, Inertia response, Etc. |
*Please refer to the latest physical product for any changes in specifications. *The table only lists some models. Products can be customized for projects.
